Solve the problem once and for all.....
choose the BK Removable
Stainless Steel Dock Ladder!
Superior craftsmanship
and high-quality raw materials immediately differentiate the BK Removable Stainless
Steel Dock Ladder from other dock ladders. The satin stainless sheen
looks good year after year, and the tig welded
components are engineered to withstand unintentional recreational mishaps
as well as the greatest wear and tear that Mother Nature herself can
deliver.
Years of "real world" testing and
continual improvements are reflected in the ladder's superior design
with the ultimate goal of providing the consumer with the best removable
stainless steel dock ladder solution on the market today. The unique
mounting system on the BK Removable Stainless Steel Dock Ladder enables
the ladder to be readily removed for seasonal dock storage or alternate
dock use. This
highly engineered design using just four bolts enables
the ladder to be easily removed and readily re-installed in just minutes!
|
|
Easy removal and re-installation
is the hallmark of the BK Removable Stainless Steel Dock Ladder. The unique mounting system uses
two mounting flanges screwed to the dock surface and two slip
support mounting flanges screwed to the dock face to secure the ladder.
The tig welded mounting posts on the ladder readily slide into the slip
support mounting flanges on the dock face. The ladder is then bolted
to the mounting flanges on the dock surface. All the necessary assembly hardware is included with the BK Removable Stainless Steel Dock Ladder.
Only the highest quality
stainless steel raw materials are used in the
fabrication of the BK Removable Stainless Steel Dock Ladder. The 1.5" diameter tubing allows for easy gripping, by even the youngest
of ladder users. The ladder is fabricated from 16 gauge (.065 wall thickness),
satin-finish type 304 series stainless steel tubing.
Installation of the BK Removable
Stainless Steel Dock Ladder is
as
QUICK and EASY as 1 - 2 - 3!
- Screw the mounting flanges to the surface of the dock.
- Bolt the two-piece ladder together and bolt it to the mounting flanges with the supplied hardware.
- Slide the slip support mounting flanges onto the ladder mounting posts and screw them to the face of the dock.
|
|
|
|
The slip support mounting flanges locate the vertical
centerline of the BK Removable Stainless Dock Ladder to
3" off
the dock face. The flanges mount using a 3" diameter
7 gauge (.180 thick) mounting plate with three countersunk mounting holes.
The mounting posts on the ladder slide into the tubular joints on the
slip support mounting flanges and are held in place by the mount ring.
The
mounting flanges are composed of an internal mounting post and a 3" diameter
7 gauge (.180 thick) plate with three countersunk holes for mounting.
The ladder tubing slides over the mounting post and is bolted into position,
as indicated at right.
The BK Removable Stainless Steel Dock Ladder has
four, 3" wide treads
with strips of antislip tape. They are fabricated from 14 gauge Type
304 Series stainless steel with a #4 satin finish. The treads are spaced
at 12" intervals
through the length of the ladder.
|
